Typical Applications
| › | Warehouse, manufacturing, small/medium retail and some cold storage applications. |
| › | Mounting heights of up to 6 metres. |
| › | General wide area illumination. |
| • | Advanced 2.4GHz Mesh networking allows creation of a facility-wide lighting infrastructure, delivering a host of added-value user benefits, all configured and controlled via the Lumiqs™ App. |
| Lighting group configuration and management. | |
| Full range dimming control. | |
| Motion sensor configuration & mode selection. | |
| Scheduling functions. | |
| Energy management visualisation (by time/day/week/month/year). | |
| Space management (heatmap visualisation). | |
| *Data Gateway required – sold separately. More info | |
|
|
|
| • | Slimline linear LED luminaire with integral intelligent motion sensor. |
| • | A perfect balance between high illuminance and anti-glare. |
| • | Integral multi-pyro PIR sensor automatically illuminates the LED light when motion is detected. Detection range up to 8m x 360 degrees. |
| • | The super bright LED light will automatically switch off in standby mode (when no occupancy is detected) or can provide constant low-level ambient illumination, dimmable between 0% – 50% of maximum brightness. |
| • | Saves up to 85% energy costs when compared to traditional HF fluorescent lighting. |
| • | Easy to install, with adjustable mounting brackets permitting use of existing mounting holes. Safety tethers included. |
Download Resources
For IES files we suggest you <right-click> (PC) or <CTRL-click> (Mac) then ‘Save as…’
- • Data Sheet
- • IES file
